ASRock X570 Extreme4, AMD X570-Mainboard - Sockel AM4 (90-MXBAP0-A0UAYZ)

Артикул: 2087

Наличие и цену уточняйте у менеджера.

Formfaktor/CPU	ATX Mainboard mit Sockel AMD AM4 für AMD Ryzen 2000/3000 Prozessoren
Chipsatz	AMD X570
Arbeitsspeicher	128 GB maximaler Arbeitsspeicher4x RAM-Slots (Steckplätze für Arbeitsspeicher)AMD Ryzen series CPUs (Matisse) support DDR4 4666+(OC) / 4400(OC) / 4300(OC) / 4266(OC) / 4200(OC) / 4133(OC) / 3466(OC) / 3200/2933/2667/2400/2133 ECC & non-ECC, un-buffered memoryAMD Ryzen series CPUs (Pinnacle Ridge) support DDR4 3600+(OC) / 3466(OC) / 3200(OC) / 2933/2667/2400/2133 ECC & non-ECC, un-buffered memoryAMD Ryzen series CPUs (Picasso) support DDR4 3466+(OC) / 3200(OC) / 2933/2667/2400/2133 non-ECC, un-buffered memoryMax. capacity of system memory: 128GB15µ Gold Contact in DIMM Slot
Graphik	Radeon Vega Grafik (Ryzen CPU) Grafikchipsatz
Steckplätze	2 PCIe 4.0 x16, 3 PCIe 4.0 x1
Interne Anschlüsse	1 x SPI TPM Header1 x Power LED and Speaker Header1 x AMD Fan LED Header1 x RGB LED Header1 x Addressable LED Header1 x CPU Fan Connector (4-pin)1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)*4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)****1 x 24 pin ATX Power Connector (Hi-Density Power Connector)1 x 8 pin 12V Power Connector (Hi-Density Power Connector)1 x 4 pin 12V Power Connector (Hi-Density Power Connector)1 x Front Panel Audio Connector (15µ Gold Audio Connector)1 x AMD LED Fan USB Header1 x Thunderbolt™ AIC Connector (5-pin) (Supports ASRock Thunderbolt™ AIC Card only)2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection)2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports) (Supports ESD Protection)1 x Front Panel Type C USB 3.2 Gen1 Header (Supports ESD Protection)
Externe Anschlüsse	2 x Antenna Ports (on I/O Panel Shield)1 x PS/2 Mouse/Keyboard Port1 x HDMI Port1 x Optical SPDIF Out Port1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (Supports ESD Protection)1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (Supports ESD Protection)6 x USB 3.2 Gen1 Ports (Supports ESD Protection)*1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
Netzwerk/ Kommunikation	1x Gigabit-LAN
Sound	Realtek ALC1220, 8-Kanal Audio
Unterstützte Betriebssysteme	Microsoft® Windows® 10 64-bit
Besonderheiten	LED Beleuchtung RGB-Anschluß CrossFireX Optical S/PDIF-Out Anschluß ASRock USB 3.2 Gen2- ASRock USB 3.2 Gen2 Type-A Port (10 Gb/s)- ASRock USB 3.2 Gen2 Type-C Port (10 Gb/s) ASRock Super Alloy- XXL Aluminum Alloy Heatsink- Premium 60A Power Choke- 50A Dr.MOS- Premium Memory Alloy Choke (Reduces 70% core loss compared to iron powder choke)- Combo Caps (Nichicon 12K Black Caps)- Nichicon 12K Black Caps (100% Japan made high quality conductive polymer capacitors)- I/O Armor- Matte Black PCB- High Density Glass Fabric PCB- 2oz Copper PCB ASRock Steel Slot Gen4 ASRock Full Coverage M.2 Heatsink ASRock Hyper M.2 (PCIe Gen4x4 & SATA3) ASRock Ultra USB Power ASRock POST Status Checker (PSC) ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update & APP Shop
Lieferumfang	Benutzerhandbuch, Treiber-CD, Slotblende, SATA-Anschlusskabel
Brand	ASRock
