| Eingebauter Prozessor | Ja |
| Prozessorhersteller | Intel |
| Prozessorfamilie | Intel® Celeron® |
| Prozessor | N4505 |
| Prozessor-Taktfrequenz | 2,9 GHz |
| Anzahl Prozessorkerne | 2 |
| Prozessor Lithografie | 10 nm |
| Prozessor-Cache | 4 MB |
| CPU Konfiguration (max) | 1 |
| Arbeitsspeicher Typ | SO-DIMM |
| Anzahl der Speichersteckplätze | 2 |
| RAM-Speicher maximal | 16 GB |
| Unterstützte Arbeitsspeicher | DDR4-SDRAM |
| Unterstützte Speicherlaufwerke | HDD & SSD |
| unterstützte Speicherlaufwerksgrößen | 2.5" |
| Speicherlaufwerk Schnittstelle | PCI Express |
| Integrierter Kartenleser | Ja |
| Kompatible Speicherkarten | SD |
| Grafikkarte-Familie | Intel |
| Eingebauter Ethernet-Anschluss | Ja |
| LAN-Controller | Intel® I211 |
| Anzahl USB 2.0 Anschlüsse | 2 |
| Anzahl USB 3.2 Gen 1 (3.1 Gen 1) Typ-A Ports | 2 |
| Anzahl HDMI-Anschlüsse | 1 |
| Anzahl VGA (D-Sub) Anschlüsse | 1 |
| Anzahl Ethernet-LAN-Anschlüsse (RJ-45) | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Anzahl der Steckplätze vom Typ A | 2 |
| Menge interner USB 2.0-Anschlüsse | 1 |
| HDMI-Version | 2.0 |
| Anzahl DisplayPort Anschlüsse | 1 |
| DisplayPorts-Version | 1.4a |
| Anzahl COM-Anschlüsse | 2 |
| Gehäusetyp | 1,35 l großer PC |
| Produktfarbe | Schwarz |
| Produkttyp | PC Barebone |
| VESA-Halterung | Ja |
| Intel® Virtualisierungstechnik für direkte I/O (VT-d) | Ja |
| Intel® VT-x mit Extended Page Tables (EPT) | Ja |
| Intel® 64 | Ja |
| Leerlauf Zustände | Ja |
| Verbesserte Intel SpeedStep Technologie | Ja |
| Intel® Trusted-Execution-Technik | Nein |
| Intel® Virtualization Technologie (VT-X) | Ja |
| Netzteiltyp | Externer AC-Adapter |
| Stromversorgung | 40 W |
| Netzteil Ausgangsspannung | 12 - 19 V |
| Temperaturbereich in Betrieb | 0 - 40 °C |
| Breite | 165 mm |
| Tiefe | 190 mm |
| Höhe | 43 mm |
| Brand | Shuttle |
