| Prozessorfamilie | Intel Xeon |
| Prozessor Taktrate | 3,5 GHz |
| Anzahl der Prozessorkerne | 6 |
| Prozessorsockel | LGA2011-v3 |
| Komponente für | Server/Arbeitsstation |
| Prozessorprozeß | 22 nm |
| Box | Nicht |
| Prozessor | E5-1650V3 |
| Prozessor Anzahl der Threads | 12 |
| Prozessorbetriebsmodi | 64-bit |
| Pufferspeicher L3 | 15 MB |
| Staffelung | R2 |
| L3 cache Schnelligkeit | 3,5 GHz |
| Turbo Frequenz (max) | 3,8 GHz |
| Bus typ | QPI |
| Maximum unterstützte RAM | 768 GB |
| Unterstützte Arbeitsspeicher | DDR4-SDRAM |
| Unterstützte Arbeitsspeichergeschwindigkeit | 1333, 1600, 1866, 2133 MHz |
| Speicherbandbreite (max.) | 68 GB/sek |
| Memory Kanäle support | Quad |
| ECC | Ja |
| Eingebaute Grafikadapter | Nicht |
| Wärmekraft | 140W |
| VID Spannungsbereich | 0.65 - 1.3V |
| Execute Disable Bit | Ja |
| Leerlauf Zustände | Ja |
| Thermal-Überwachungstechnologien | Ja |
| PCI Express slots Anzahl | 40 |
| PCI-Express-Slots-Version | 3.0 |
| Unterstützte Befehlssätze | AVX |
| Skalierbarkeit | 1S |
| Physical Address Extension (PAE) | Ja |
| Eingebettete Optionen verfügbar | Nicht |
| Intel Hyper-Threading Technologie | Ja |
| Intel Identity Protection Technologie | Ja |
| Intel Turbo Boost Technologie | 2.0 |
| Intel vPro Technologie | Ja |
| Intel Flex Memory Access | Nicht |
| Intel Smart Cache | Ja |
| Intel AES New Instructions | Ja |
| Verbesserte Intel SpeedStep Technology | Ja |
| Intel Trusted Execution Technology | Ja |
| Intel Virtualization Technology | VT-d, VT-x |
| Intel Enhanced Halt State | Ja |
| Intel VT-x mit Extended Page Tables (EPT) | Ja |
| Intel Demand Based Switching | Ja |
| Intel Sicherer Schlüssel | Ja |
| Intel TSX-NI | Nicht |
| OS-Guard | Ja |
| Tcase | 66,7 °C |
| Packungsgröße | 52,5 x 45 mm |
| CPU Konfiguration (max) | 1 |
| Prozessor-Code | SR20J |
| Brand | Intel |
