| Eingebaut | Ja |
| Hostschnittstelle | PCIe |
| Produktfarbe | Schwarz, Grün |
| Analoges Signalformatsystem | NTSC,PAL |
| Unterstütze Auflösung | 640x480p60, 800x600p50, 800x600p60, 1440x900p50 1440x900p60, 1440x1080p50 1440x1080p60, 1600x1200p50, 1600x1200p60, 1920x1200p50, 1920x1200p60, 1920x1440p50, 1920x1440p60, 2560x1440p50, 2560x1440p60, 2560x1600p50, 2560x1600p60 |
| Video-Codec | AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR, DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy |
| Unterstützte Video-Modi | 720p,1080i,1080p,2160p |
| Anzahl HDMI-Anschlüsse | 4 |
| HDMI-In | 4 |
| Gewicht | 128 g |
| Tiefe | 109 mm |
| USB | Nein |
| Mitgelieferte Software | Media Express, Disk Speed Test, Blackmagic Desktop Video Utility |
| Unterstützt Windows-Betriebssysteme | Windows 10,Windows 7,Windows 8.1 |
| Mac-Kompatibilität | Ja |
| Unterstützt Mac-Betriebssysteme | Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave |
| Unterstützte Linux-Betriebssysteme | Ja |
| Temperaturbereich in Betrieb | 5 - 40 °C |
| Temperaturbereich bei Lagerung | 20 - 45 °C |
| Luftfeuchtigkeit in Betrieb | 0 - 90% |
| Betriebsanleitung | Ja |
| Anzahl | 1 |
| Zertifizierung | FCC, CE, RCM, KC |
| Brand | Blackmagic |
